Chipset Type SiS761GX / SiS965L
Compatible Processors Athlon 64, Sempron
Processor Socket Socket 754
Max Bus Speed 800 MHz
Max Processors Qty 1
ManufacturerPCChips USA, Inc.
EXPANSION / CONNECTIVITY
Expansion Slots 1 x CPU
2 x DIMM 184-pin (2.5 V)
2 x PCI
1 x PCIe x16
1 x AGP Pro
1 x CNR
Storage Interfaces ATA-133 -connectors: 2 x 40pin IDC - 4 devices
SATA-150 -connectors: 2 x 7pin Serial ATA - 2 devices
Internal Interfaces 1 x floppy
Additional Connectors (Optional) 4 x USB 2.0
Power Connectors 4-pin ATX12V connector, 24-pin main power connector
PROCESSOR
Max Supported Qty 1
Installed Qty 0
MEMORY
Memory Allocation Technology shared video memory (UMA)
Max Allocated RAM Size 64 MB
MISCELLANEOUS
Product Type motherboard
INTERFACE PROVIDED
Qty 1, 4
Type LAN, PS/2 keyboard, PS/2 mouse, USB 2.0, VGA, audio line-in, audio line-out, microphone, parallel, serial
Connector Type mini-jack
PROCESSOR / MEMORY / STORAGE
Max Supported Qty 1
NETWORKING
Data Link Protocol Ethernet, Fast Ethernet
Network Controller Realtek RTL8201CL
Network Ethernet
AUDIO
Audio Codec AD1888
Compliant Standards AC '97
RAM
Max Supported Size 2 GB
AUDIO OUTPUT
Sound Output Mode 5.1 channel surround
Compliant Standards AC '97
Type sound card
Audio Codec AD1888
Audio 6-channel
GRAPHICS
Max Allocated RAM Size 64 MB
Graphics Controller SiS Mirage 1
Memory Allocation Technology Shared video memory (UMA)
VIDEO
Video Output graphics adapter
Graphics Processor SiS Mirage 1
LAN
Network Interfaces Ethernet
Network Controller Realtek RTL8201CL
SUPPORTED RAM
Bus Clock 400 MHz
Speed PC3200
Technology DDR
Max Size 2 GB
HEADER
Brand PCCHIPS
Product Line PCCHIPS
Model A31G
Packaged Quantity 1
Compatibility PC
Revision 1.1
MAINBOARD
Form Factor micro ATX
Processor Socket Socket 754
Compatible Processors Athlon 64, Sempron
Data Bus Speed 800 MHz
Chipset Type SiS761GX
I/O Controller SiS965L
Supported RAM Technology DDR SDRAM
Supported RAM Speed 400 MHz
Supported RAM Standard PC3200
Power Connectors 24-pin main power connector, 4-pin ATX12V connector
MAINBOARD FEATURES
BIOS Type AMI
BIOS Features ACPI 1.0 support, APM 1.2 support, DMI support, Multi Boot
INTERFACES
Storage ATA-133, Serial ATA-150
EXPANSION SLOTS
Total Qty 1, 2
Voltage 2.5 V
Type CPU, DIMM 184-pin, PCI, PCIe x16
SOFTWARE
Software Included drivers & utilities
DIMENSIONS & WEIGHT
Width 9.6 in
Depth 7.9 in
VIDEO MEMORY
Memory Allocation Technology shared video memory (UMA)
Max Allocated RAM Size 64 MB
STORAGE INTERFACES
Interface ATA-133, Serial ATA-150
Connector(s) 2 x 40pin IDC, 2 x 7pin Serial ATA
Supported Devices Qty 2, 4
INTERNAL INTERFACES
Type floppy
Qty 1
FEATURES
BIOS Type AMI
BIOS Features DMI support, APM 1.2 support, ACPI 1.0 support, Multi Boot
GENERAL
ManufacturerPCChips USA, Inc.
Where to Buy
PCCHIPS A31G - 1.1 - motherboard - micro ATX - Socket 754 - SiS761GX
Part Number: A31G V1.1
